Single / Double PE Coated Paper Box Making Machine For Meal Box , Chips Box

Single / Double PE Coated Paper Box Making Machine For Meal Box , Chips Box

Single / Double PE Coated Paper Box Making Machine For Meal Box , Chips Box

Product Details:

Place of Origin: China
Brand Name: RUIZE
Certification: CE
Model Number: CH-10

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 25sets/month
Contact Now
Detailed Product Description
Product Name: Paper Lunch Box Making Machine Paper Box Size: Max 160*140*45 Min 100*60*20
Production Rate: 55-60 PCS/min Air Consumption: 0.18-0.25m3/min;0.45Mpa
Total Power: 4KW Power Source: 380V

Single / Double PE Coated Paper Box Making Machine For Meal Box , Chips Box



Description:



1. Feature of stereo box die-cutter: high efficiency

2. Multifunctionality: can manufacture the products such as meal box, chips box, stereo box

or burger box with different specifications on one machine only by changing its molds.

3. This machine applies water-based adhesive coating device, attains high efficiency and very

high precision. Water-based adhesive, as water soluble adhesive compostion, is a kind of

food-grade glue.

4. Most of the machine applies high-quality sealing bearing, prevents from dust or liquid

penetrating and impacting the service life of bearings, with long service life and good stability.

5. The whole is driven by high-quality tinming belts and ensures almost zero error during its operation.

6. Main mould employs pine wood, enjoys high efficiency when replacing its mould.

7. Can automatically collect, store and count finished products, and install additionally counter as

per the requirements of customers.

8. The machine applies PLC intelligent control system, and automatically stop when there is paper

jamming or no paper. It can avoid unnecessary harm caused by the contact between worker

and operation mechanism during the production process.





Applications:



Supply For burger box, hot-dog box, one block box, food pail box, fries box, lunch box etc.





Specifications:



No. Item CH-09
paper type single or double PE coated paper
Size Max 160*140*45 Min 100*60*20
production rate 50-55pcs / min
Power source 380V
Total power 5.5KW
Total power consumption 4Kw
Consumption of air 0.2-0.25m3/min;0.4Mpa;
Machine Weight 1000KG
Machine size 1549 * 720 * 1500mm





FAQ



Wha't the product time?

Normal about 30days of order 1-5 sets machine.



What's the payment?

TT.30% payment in advance, pay the balance before shipment.

Some country can accept L/C.



What about the shipment?

We can send the machine to the customer designated locations in China.



After receiving machine, if machine have questions.

We can send engineer to you your country. Customer should pay for engineer and the freight.
